Your are here: Home >> Products >>Rotary Type Autoclave(Sterilizer)
Rotary type autoclave have advantages of energy saving, high productivity, automatically display temperature control, wide adjustment range, high control precision, corrosion-resistant muffler, easy to clean, etc., widely used in food, juice, pharmaceutical, chemical, beverage and other industries, as necessary equipment to heat, cool, insulate, sterilize, handle and store.
Directory
- Classification of Autoclave
- Usages of Rotary Type Autoclave
- Characteristics of Rotary Type Autoclave
- Technical Paremeters of Automtic
- Technical requirements of Automtic
- Rotary Type Autoclave Finished Picture
Classification of Autoclave
1. According to material, there are SUS304 and carbon steel（Q235-B）
2. According to heating type, it can be divided into steam heating and electric heating.
3. According to control type, it can be divided into manual control, semiautomatic control and automatic control.
Usages of Rotary Type Autoclave
Apply to cans (such as: meat, poultry, fish, eggs, canned vegetables, etc) and requires high temperature sterilization.
Protein drinks (such as: milk, soy milk, almond, coconut milk, peanut milk, walnut milk, etc.)
Protein drinks (such as: milk, soy milk, almond, coconut milk, peanut milk, walnut milk, etc.)
Characteristics of Rotary Type Autoclave
1. Semi-automatic computer control the temperature, sterilization time, pressure protection, product cooling.
2. Energy saving and easy to operate.
3. The sterilization equipment can use hot water cycle sterilization and steam sterilization.
4. It is suitable for vacuum package, cans, glass bottles, and plastic package, edible and other food.
5. Setting several sterilization processes according to different products.
Technical Paremeters of Automtic
|
Volume |
600L |
1100L |
1900L |
2200L |
3100L |
4000L |
|
Body diameter （mm） |
800 |
900 |
1000 |
1100 |
1100 |
1200 |
|
Body length （mm） |
1000 |
1500 |
2000 |
2000 |
3000 |
3000 |
|
Material |
SUS304/ Q235-B | |||||
|
Designed pressure |
0.35MPa | |||||
|
Working pressure |
＜0.3MPa | |||||
|
Designed temperature |
140.7℃ | |||||
|
Working temperature |
＜135℃ | |||||
Notes:
1. The parameters of autoclave in the chart are standard configurations. Any specific requirements, please let us know.
2. The process parameters that need provided when choosing the retorts: the nature of material, sterilization process, specific requirements, etc.
3. Accessories: storage gas tank, air compressor, water tank, boiler.
Technical requirements of Automtic
1. File support: the structural size drawing of the device (PDF) and instructions are available.
2. Required by operated function, the following criteria are adopted to design, manufacture and test
A. << Standards for quality control of pharmaceutical production (Revised 1998)>> terms of Chapter IV 31-37;
B. << The Steel Pressure Vessel (GB150-1998)>>;
C. << The Steel Welding Normal Pressure Vessel (JB/T 4735-1997)>>;
D. << Food Machinery Safety and Heath (GB 16798-1997)>>.
Rotary Type Autoclave Finished Picture
